Reverse Engineering Services
REVERSE ENGINEERING FROM EXISTING PARTS
Reverse engineering recreates a digital CAD model from a physical part — useful when original design files are missing, a part is obsolete, or a component needs to be modified or replaced. KS Projects provides reverse engineering services for U.S. companies, turning physical samples into manufacturing-ready files.
3D SCANNING / MEASUREMENT / CAD RECREATION
Depending on the part's complexity, we use manual measurement, 3D scanning, or a combination of both to capture accurate geometry. The captured data is then rebuilt as a clean, editable CAD model — not just a raw scan mesh — so the file can be modified, analyzed, or sent directly to manufacturing.
OBSOLETE OR CUSTOM PARTS
Reverse engineering is especially useful for legacy equipment where original drawings no longer exist, discontinued components that need to be remanufactured, and custom parts that require redesign or improvement based on an existing physical sample.
MANUFACTURING-READY FILES
The final deliverable is a clean CAD model and manufacturing drawing — ready to send to a supplier, not a raw scan file. We can also rebuild a bill of materials (BOM) for assemblies with multiple parts.
USE CASES
-
Recreating CAD files for legacy industrial equipment
-
Sourcing replacement parts when the original manufacturer is unavailable
-
Redesigning an existing part to fix a recurring failure
-
Digitizing a competitor or reference product for design comparison
FAQ
What are reverse engineering services?
DELIVERABLES
Reverse engineering services recreate an accurate CAD model from a physical part, typically when original design files are missing or the part needs to be modified.
DELIVERABLES
When is reverse engineering useful?
It is most useful for obsolete components, legacy equipment without original drawings, or when a physical sample needs to be turned into editable, manufacturing-ready files.
Can you recreate CAD models from existing parts?
Yes. We use measurement and 3D scanning techniques to capture accurate geometry, then rebuild it as a clean, editable CAD model.
What files or samples are needed for reverse engineering?
A physical sample of the part is usually required, either shipped to us or scanned locally and shared as point-cloud data, depending on the project.
Can reverse engineering help with obsolete parts?
Yes. This is one of the most common reasons companies use reverse engineering — to keep legacy equipment running when original parts are no longer available.
Do you provide manufacturing drawings from existing parts?
Yes. The final deliverable includes manufacturing-ready drawings, not just a 3D scan, so the part can be sent directly to a supplier for production.
